OEM#: H686New OEM Original Outright

CONDENSER FAN MOTOR 1 HP 850 RPM 60 HZ by Regal Beloit America, Inc. (Century Electric Motors)

Your price:
$919.41 eachReady to ship
HomeRegal Beloit America, Inc. (Century Electric Motors)h686
CONDENSER FAN MOTOR 1 HP 850 RPM 60 HZ by Regal Beloit America, Inc. (Century Electric Motors)
CONDENSER FAN MOTOR 1 HP 850 RPM 60 HZ by Regal Beloit America, Inc. (Century Electric Motors)

OEM#: H686
CONDENSER FAN MOTOR 1 HP 850 RPM 60 HZ by Regal Beloit America, Inc. (Century Electric Motors)

New OEM Original Outright
Your price:
$919.41 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: H686 Key Specs
Item
CONDENSER FAN MOTOR 1 HP 850 RPM 60 HZ
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
H686
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
6-1/2 in
Duty
Continuous
Frame
56Y
Full Load Amps
4.4-4/2
HP
1
Hz
60
Ins. Class
B
Length Less Shaft
9-3/8 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
3-Phase
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
Vertical Shaft Up
Motor Mounting Type
Band
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Nameplate RPM
850
Nominal Efficiency
72 %
Number of Speeds
1
Overall Length
14-1/4 in
Phase
3
Shaft Diameter
5/8 in
Shaft Length
4-7/8 in
Standards
UL Recognized (E46412/E44549), CSA Certified (LR43341/LR4642)
Voltage
200-230/460
