OEM#: C060New OEM Original Outright
MOTOR PSC 3/4 HP 1075 115/230V 56 TENV by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$493.20 each
OEM#: C060MOTOR PSC 3/4 HP 1075 115/230V 56 TENV by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$493.20 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: C060 Key Specs
Item
MOTOR PSC 3/4 HP 1075 115/230V 56 TENV
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
C060
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Blowers, Fans and Air Circulators
Body Diameter
6-1/2 in
Bolt Circle Diameter
5-13/16 in
Capacitor Required
Included
Country of Origin
Mexico
Duty
Continuous
Frame
56
Full Load Amps
7.3/3.7
HP
3/4
Hz
60
Includes
Resilient Base
Ins. Class
B
Length Less Shaft
9-5/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed Nonventilated
Motor Mounting Position
All Angle
Motor Mounting Type
Cradle Base
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CCWLE
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Location
Shaft End
Mounting Stud Pattern
4-1/8 in x 4-1/8 in
Nameplate RPM
1075
Number of Speeds
1
Phase
1
Resilient Ring Diameter
2-1/2 in
Ring to Ring Center
8-7/8 in
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA, UL
Stud Size
#10-32
Voltage
115/230
Voltage Compatibility
115, 115/230, 120, 120/240, 230, 240
