OEM#: ST1072New OEM Original Outright
MOTOR 3/4 HP 3 450 RPM 56J 115/230V by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$345.46 each $351.34 Savings: $5.88 (2%)
OEM#: ST1072MOTOR 3/4 HP 3 450 RPM 56J 115/230V by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$345.46 each
$351.34 Savings: $5.88 (2%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: ST1072 Key Specs
Item
MOTOR 3/4 HP 3 450 RPM 56J 115/230V
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
ST1072
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature
50 Degrees C
Approvals, Certifications & Standards
CSA Certified (LR43341/LR94643), UL 1081 Approvable, UL Recognized (E44549/E25022)
Finish
Black
Frame
56J
Full Load Amps
15/7.5
Horsepower
3/4
Hz
60
Insulation Class
B
Motor Application
Pump
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Open Dripproof
Motor Flange Material
Aluminum
Motor Mounting Type
Face
Motor Service Factor
1.5
Motor Shaft Rotation
CCWSE
Motor Sub Application
Pool and Spa Pump
Motor Thermal Protection
Auto
Nameplate RPM
3450
Phase
1
RPM Range
3001-3600
Shaft
Threaded 7/16-20 UNF-2A RH 11/16 in From End
Shaft Diameter
5/8 in
Shaft Length
2-9/16 in
Shaft Material
303 Stainless Steel
Voltage
115/230
Voltage Compatibility
115, 115/230, 120, 120/240, 230, 240
