OEM#: SGF2034V3New OEM Original Outright
MOTOR SP PH 1/3 HP 1725/850 115V 56Z ODP by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$570.41 each
OEM#: SGF2034V3MOTOR SP PH 1/3 HP 1725/850 115V 56Z ODP by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$570.41 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: SGF2034V3 Key Specs
Item
MOTOR SP PH 1/3 HP 1725/850 115V 56Z ODP
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
SGF2034V3
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
6-1/2 in
Duty
Continuous
Frame
56Z
Full Load Amps
5.2/3
HP
1/3 to 1/15
Hz
60
Includes
5/8 in dia Shaft Bushing
Ins. Class
B
Length Less Shaft
9-3/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Cradle Base
Motor Service Factor
1
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Belt Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
4-1/8 in x 4-1/8 in
Nameplate RPM
1725/850
Nominal Efficiency
64 %
Number of Speeds
2
Overall Length
11 1/16 in
Phase
1
Resilient Ring Diameter
2-1/2 in
Ring to Ring Center
8-11/16 in
Shaft Diameter
1/2 in
Shaft Length
1-7/8 in
Standards
CSA Certified, UL Recognized
Voltage
115
Voltage Compatibility
115, 120
