OEM#: RB2014New OEM Original Outright
MOTOR SPLIT PH 1/6 HP 1725 115V 48Z OPEN by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$244.35 each
OEM#: RB2014MOTOR SPLIT PH 1/6 HP 1725 115V 48Z OPEN by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$244.35 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: RB2014 Key Specs
Item
MOTOR SPLIT PH 1/6 HP 1725 115V 48Z OPEN
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
RB2014
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
1/2 in
Country of Origin
Mexico
Duty
Continuous
Frame
48Z
Full Load Amps
5.1
HP
1/6
Hz
60
Ins. Class
B
Length Less Shaft
1/2 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Enclosure Design
Open Air-Over
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Cradle Base
Motor Service Factor
1.35
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Belt Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
1/2 in
Nameplate RPM
1725
Number of Speeds
1
Overall Length
1/2 in
Phase
1
Resilient Ring Diameter
2-1/2 in
Ring to Ring Center
1/2 in
Shaft Diameter
1/2 in
Shaft Length
1/2 in
Standards
CSA Certified, UL Recognized
Voltage
115
Voltage Compatibility
115, 115/208-230, 115/230, 120, 120/240
