OEM#: H887LNew OEM Original Outright

MTR 3 PH 3 HP 1725 200-230/460V EFF 83.1 by Regal Beloit America, Inc. (Century Electric Motors)

Your price:
$611.72 each
$916.75 Savings: $305.03 (33%)
Ready to ship
HomeRegal Beloit America, Inc. (Century Electric Motors)H887L
MTR 3 PH 3 HP 1725 200-230/460V EFF 83.1 by Regal Beloit America, Inc. (Century Electric Motors)
MTR 3 PH 3 HP 1725 200-230/460V EFF 83.1 by Regal Beloit America, Inc. (Century Electric Motors)

OEM#: H887L
MTR 3 PH 3 HP 1725 200-230/460V EFF 83.1 by Regal Beloit America, Inc. (Century Electric Motors)

New OEM Original Outright
Your price:
$611.72 each
$916.75 Savings: $305.03 (33%)
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: H887L Key Specs
Item
MTR 3 PH 3 HP 1725 200-230/460V EFF 83.1
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
H887L
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
6-1/2 in
Duty
Continuous
Frame
56HZ
Full Load Amps
9.4-8.9/4.5
HP
3 hp
Hz
60
Ins. Class
F
Length Less Shaft
12-1/4 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
3-Phase
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Belt Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
5-13/16 in x 5-13/16 in
Nameplate RPM
1725
Nominal Efficiency
83.1 %
Number of Speeds
1
Overall Length
14-9/16 in
Phase
3
Shaft Diameter
7/8 in
Shaft Length
2-5/16 in
Standards
CSA Certified (LR4642), UL Recognized (E44549)
Voltage
200-230/460
