OEM#: GF2014New OEM Original Outright
MOTOR SPLIT PH 1/6 HP 1725 115V 48 OPEN by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$175.00 each $277.67 Savings: $102.67 (37%)
OEM#: GF2014MOTOR SPLIT PH 1/6 HP 1725 115V 48 OPEN by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$175.00 each
$277.67 Savings: $102.67 (37%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: GF2014 Key Specs
Item
MOTOR SPLIT PH 1/6 HP 1725 115V 48 OPEN
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
GF2014
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
5-5/8 in
Duty
Continuous
Frame
48
Full Load Amps
5.1
HP
1/6
Hz
60
Includes
5/8 in dia Shaft Bushing
Ins. Class
B
Length Less Shaft
7-3/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Sleeve
Motor Design
Split-Phase
Motor Enclosure Design
Open Air-Over
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Cradle Base
Motor Service Factor
1.35
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Belt Drive Fan/Blower
Motor Thermal Protection
Auto
Nameplate RPM
1725
Nominal Efficiency
46 %
Number of Speeds
1
Overall Length
8-7/8 in
Phase
1
Resilient Ring Diameter
2-1/2 in
Ring to Ring Center
6-15/16 in
Shaft Diameter
1/2 in
Shaft Length
1-1/2 in
Standards
CSA Certified (LR43341), UL Recognized
Voltage
115
Voltage Compatibility
115, 120
