OEM#: FEH1026SFNew OEM Original Outright
CONDENSER FAN MOTOR 1/4 HP 1075 RPM 60HZ by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$361.18 each
OEM#: FEH1026SFCONDENSER FAN MOTOR 1/4 HP 1075 RPM 60HZ by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$361.18 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: FEH1026SF Key Specs
Item
CONDENSER FAN MOTOR 1/4 HP 1075 RPM 60HZ
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
FEH1026SF
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
5-5/8 in
Capacitor Required
2MDV6
Country of Origin
Mexico
Duty
Continuous
Frame
48Y
Full Load Amps
1
HP
1/4 in
Hz
60
Ins. Class
F
Lead Length
27 in
Length Less Shaft
4-3/4 in
Max Ambient Temperature
70 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Nominal Efficiency
67 %
Number of Speeds
1
Overall Length
10-3/4 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
6 in
Standards
UL Recognized (E46412), CSA Certified (LR43341)
Stud Quantity
4
Stud Size
8-32 x 7/8, 8-32 x 9/16 in
Voltage
460
