OEM#: FE1016SFNew OEM Original Outright
CONDENSER FAN MOTOR 1/6 HP 1075 RPM 60HZ by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$196.93 each
OEM#: FE1016SFCONDENSER FAN MOTOR 1/6 HP 1075 RPM 60HZ by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$196.93 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: FE1016SF Key Specs
Item
CONDENSER FAN MOTOR 1/6 HP 1075 RPM 60HZ
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
FE1016SF
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
5-5/8 in
Capacitor Required
2MDV4
Country of Origin
China
Duty
Continuous
Frame
48Y
Full Load Amps
1.3-1.4
HP
1/6
Hz
60
Ins. Class
F
Lead Length
36 in
Length Less Shaft
4-13/16 in
Max Ambient Temperature
70 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Number of Speeds
1
Overall Length
10-13/16 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
6 in
Standards
UL Recognized (E25022), CSA Certified (LR 43341)
Stud Quantity
4
Stud Size
8-32
Voltage
208-230
