OEM#: FT-2KIT

5.5 X 3.25 X 2 IN INFUSION PUMP ANALYZER by Pronk Technologies Inc

The first palm-size Infusion Pump Analyzer, FlowTrax has numerous features in a very small affordable and portable package while rivaling the larger, more expensive competitive products with impressive accuracy and speed. IV pumps can now be tested for Flow Rate and Volume in 3 minutes or less within a 1% accuracy using FlowTrax patent-pending fluid tracking technology. FlowTrax includes all the features of more expensive larger IV Pump Analyzers a full featured pressure temperature meter and a digital stopwatch four pieces of test equipment in a single device.

Unique Fluid Detection System

FlowTrax was designed with a patent-pending dynamic fluid detection system which enables FlowTrax to track fluid movement in real time. This measurement system provides 1200 measurement points in a 1ml fluid column, thus providing superior accuracy in fluid volume and rate calculations over traditional analyzers.

• Powered by two AA (Alkaline or Lithium) cells or 6 VDC Input
• Battery Life Alkaline: Min. 4 hours Lithium: Min. 12 hours

Pressure Performance

• Range -12.5 to 75 PSI
• Accuracy 0.5% of reading ± 1 LSD
• Resolution 0.01 PSI
• Units of Measure mmHg, PSI (gauge), inH2O, cmH2O, kPa, atm, inHg, BAR (absolute), BAR (gauge)

Temperature Performance

• Range -28.9° to +115.5° C
• Accuracy 0.1% ± 0.2 degrees C
• Resolution 0.1° C

Digital Timer/Stopwatch

• Range 0 to 12 hours
• Accuracy 0.5%

• Results within 1% accuracy for rates from 1 ml/hr to 999 ml/hr in less than 3 minutes
• Quick Prime feature rapidly readies unit for use - no stopping to re-prime between tests!
• Electronic Occlusion feature
• Test any type of infusion device from PCA, syringe, volumetric to feeding pumps and more.
• Up to 40X faster than other products - requires as little as little as 0.5 ml volume for low rate tests to achieve w/in 1% accuracy
• Never miss a test result with Trend feature
• Capture real-time results to any file, form or record on your PC with DataSnap
• Market-best measurement resolution of 0.0008 milliliters
• Patent-pending dynamic fluid detection system tracks fluid movement in real-time with 1,200 measurement points in a 1-ml fluid column, yielding superior accuracy in fluid volume and rate calculations over any other analyzer

The first palm-size Infusion Pump Analyzer, FlowTrax has numerous features in a very small affordable and portable package while rivaling the larger, more expensive competitive products with impressive accuracy and speed. IV pumps can now be tested for Flow Rate and Volume in 3 minutes or less within a 1% accuracy using FlowTrax patent-pending fluid tracking technology. FlowTrax includes all the features of more expensive larger IV Pump Analyzers a full featured pressure temperature meter and a digital stopwatch four pieces of test equipment in a single device.

Unique Fluid Detection System

FlowTrax was designed with a patent-pending dynamic fluid detection system which enables FlowTrax to track fluid movement in real time. This measurement system provides 1200 measurement points in a 1ml fluid column, thus providing superior accuracy in fluid volume and rate calculations over traditional analyzers.

• Powered by two AA (Alkaline or Lithium) cells or 6 VDC Input
• Battery Life Alkaline: Min. 4 hours Lithium: Min. 12 hours

Pressure Performance

• Range -12.5 to 75 PSI
• Accuracy 0.5% of reading ± 1 LSD
• Resolution 0.01 PSI
• Units of Measure mmHg, PSI (gauge), inH2O, cmH2O, kPa, atm, inHg, BAR (absolute), BAR (gauge)

Temperature Performance

• Range -28.9° to +115.5° C
• Accuracy 0.1% ± 0.2 degrees C
• Resolution 0.1° C

Digital Timer/Stopwatch

• Range 0 to 12 hours
• Accuracy 0.5%
