OEM#: Y8MFA1003New OEM Original Outright

COMPACT Y BLOCK OXYGEN FLOWMETER, 0 TO 15 LPM FLOW, POLYCARBONATE HOUSING, ALUMINUM BODY, DISS FEMALE HANDTIGHT, VERSATILE by Precision Medical, Inc.

Your price:
$91.20 each
HomePrecision Medical, Inc.Y8MFA1003
COMPACT Y BLOCK OXYGEN FLOWMETER, 0 TO 15 LPM FLOW, POLYCARBONATE HOUSING, ALUMINUM BODY, DISS FEMALE HANDTIGHT, VERSATILE by Precision Medical, Inc.
COMPACT Y BLOCK OXYGEN FLOWMETER, 0 TO 15 LPM FLOW, POLYCARBONATE HOUSING, ALUMINUM BODY, DISS FEMALE HANDTIGHT, VERSATILE by Precision Medical, Inc.
COMPACT Y BLOCK OXYGEN FLOWMETER, 0 TO 15 LPM FLOW, POLYCARBONATE HOUSING, ALUMINUM BODY, DISS FEMALE HANDTIGHT, VERSATILE by Precision Medical, Inc.

OEM#: Y8MFA1003
COMPACT Y BLOCK OXYGEN FLOWMETER, 0 TO 15 LPM FLOW, POLYCARBONATE HOUSING, ALUMINUM BODY, DISS FEMALE HANDTIGHT, VERSATILE by Precision Medical, Inc.

New OEM Original Outright
Your price:
$91.20 each
Asset Information
ADD TO LIST
Product Overview

The DISS “Y” Block assembly allows two compact flowmeters to be installed using one wall outlet. Constructed of lightweight aluminum, the Y Block is used to deliver oxygen or medical air to two separate clinical areas. The optional power take off (demand valves) allows the attachment of a ventilator, flowmeter, resuscitation bag or suction regulator.

  • The polycarbonate housings are extremely durable. they are impervious to chemical solutions normally used in a clinical setting preventing clouding and spidering
  • Their exceptional sphericity and uniform weight contribute to a more accurate flowmeter than those using plastic floats
  • Highly accurate needle valves insure precise flow-settings the first time
  • The flow control knob is on the front of the flowmeter in clear sight of the operator unlike side mount knobs which are susceptible to damage during installation of additional equipment
  • Exceptional sphericity and uniform weight contribute to a more accurate flowmeter than those using plastic floats

Technical Specs

P/N: Y8MFA1003 Key Specs

Item
COMPACT Y BLOCK OXYGEN FLOWMETER, 0 TO 15 LPM FLOW, POLYCARBONATE HOUSING, ALUMINUM BODY, DISS FEMALE HANDTIGHT, VERSATILE
OEM
Precision Medical, Inc.
OEM #
Y8MFA1003
Condition
New OEM Original
Returnable
No
Accuracy
+/-0.25 lpm 0.5 to 5 lpm, +/-0.5 lpm above 6 to 15 lpm
Connection Data
DISS Female Handtight
Connection Type
DISS Female Hand Tight
Finish
Chrome Plated
Flow Control Type
Adjustable
Flow Range
0 LPM - 15 LPM
Flow Rating
0 to 15 LPM
Gas Type
Oxygen
Material
Polycarbonate Housing, Aluminum Body
Pressure Rating
50 PSI
Temperature Rating
70 Deg F
Equivalents
Certifications
Minority OwnedMinority OwnedVeteran-Owned (VOB)Veteran-Owned (VOB)ISO 13485 Medical DevicesISO 13485 Medical DevicesSBASBA

The DISS “Y” Block assembly allows two compact flowmeters to be installed using one wall outlet. Constructed of lightweight aluminum, the Y Block is used to deliver oxygen or medical air to two separate clinical areas. The optional power take off (demand valves) allows the attachment of a ventilator, flowmeter, resuscitation bag or suction regulator.

  • The polycarbonate housings are extremely durable. they are impervious to chemical solutions normally used in a clinical setting preventing clouding and spidering
  • Their exceptional sphericity and uniform weight contribute to a more accurate flowmeter than those using plastic floats
  • Highly accurate needle valves insure precise flow-settings the first time
  • The flow control knob is on the front of the flowmeter in clear sight of the operator unlike side mount knobs which are susceptible to damage during installation of additional equipment
  • Exceptional sphericity and uniform weight contribute to a more accurate flowmeter than those using plastic floats

  • Y8MFA1003: Medical Fittings (Precision Medical): Canonical Redirect
