OEM#: PM3316HVNew OEM Original Outright

3.7 L X 2.8 W X 5.2IN H ANALOG VACUUM REGULATOR by Precision Medical, Inc.

Your price:
$508.93 eachReady to ship
HomePrecision Medical, Inc.PM3316HV
3.7 L X 2.8 W X 5.2IN H ANALOG VACUUM REGULATOR by Precision Medical, Inc.
3.7 L X 2.8 W X 5.2IN H ANALOG VACUUM REGULATOR by Precision Medical, Inc.
3.7 L X 2.8 W X 5.2IN H ANALOG VACUUM REGULATOR by Precision Medical, Inc.

OEM#: PM3316HV
3.7 L X 2.8 W X 5.2IN H ANALOG VACUUM REGULATOR by Precision Medical, Inc.

New OEM Original Outright
Your price:
$508.93 each

Regulator, Vacuum, 2.8in Width, 5.2in Height, 3.7in Length, Analog Gauge Type, Continuous/Intermittent Three Mode (0 to 300mmHG) Mode, Ohmeda Quick Connect (Vacuum Source), DISS Male (Patient) Connection Type

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
  • Chemtron x DISS male connection with 0 to 300 mm Hg high range vacuum gauge
  • The unique modular design makes service a breeze for any biomedical or central supply department. Continuous/Intermittent Vacuum Regulator is made up of eight (8) easy to replace modular components
  • Unlike the plastic inlet and outlet connections on most competitor’s units, the cast metal backplate connections are extremely durable, saving down time and unnecessary repair costs
  • As a result of its modular design, the unit is 25-50% smaller than other suction regulators making it the product of choice for crowded wall and rail areas
  • The case is made of strong ABS plastic and houses the gauge for extra protection
  • The smooth surface and rounded corners of the housing make cleaning and disinfection wipe down easier
  • The large control knob and easy-to-read settings make vacuum adjustments simple, even in emergency situations
    • Features
    • Factory preset timing cycles set at approximately 16 seconds On, 8 seconds Off
    • Fully adjustable, 2-to-1 ratio timing cycles
    • Modular components are attached to a cast metal back plate, simplifying service
    • Low to high vacuum rates
    • Large, easy-to-grip knobs
    Technical Specs
    P/N: PM3316HV Key Specs
    Item
    3.7 L X 2.8 W X 5.2IN H ANALOG VACUUM REGULATOR
    OEM
    Precision Medical, Inc.
    OEM #
    PM3316HV
    Condition
    New OEM Original
    Returnable
    No
    Warranty
    90 Day
    Battery Volts
    3 V
    Connection Type
    Chemtron x DISS Male
    Display Type
    Analog
    Flow rate
    0 - 300 MMHG
    Material
    Plastic
    Maximum Gauge Accuracy
    ± 5 %
    Number of Modes
    3
    Operating Temperature Range
    0°F - 122°F (-18°C - 50°C)
    Pressure Rating
    0 to 300 mm Hg
    Regulator Modes
    Continuous/Intermittent
    Storage Humidity
    0.95
    Storage Temperature Range
    -4°F - 140°F (-20°C - 60°C)
    Vacuum Source Connection
    Ohmeda Quick Connect
