OEM#: ICN-4P16-TLED-NNew OEM Original Outright
LED DRIVER 120 TO 277VAC 9-1/2 IN L. by Philips Lighting
Your price:
$38.68 each
OEM#: ICN-4P16-TLED-NLED DRIVER 120 TO 277VAC 9-1/2 IN L. by Philips Lighting
New OEM Original Outright
Your price:
$38.68 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: ICN-4P16-TLED-N Key Specs
Item
LED DRIVER 120 TO 277VAC 9-1/2 IN L.
OEM
Philips Lighting
OEM #
ICN-4P16-TLED-N
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature Range
-13 Degrees to 113 Degrees F
Approvals, Certifications & Standards
UL
Ballast Dimming Type
No Dimming
Brand & Series
Centium
Bulb Shape
UL Type C
Case Form Factor
Long
Country of Origin
Mexico
Dimming Method
No Dimming
Dimming Range
No Dimming
Dimming Type
No Dimming
Driver Class
Class P
Driver Mounting Location
Within Fixture
Environmental Rating
Damp Location, Dry Location
For Use With
LED T8 Type C Tubes
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Height
1 in
Input Current
0.61 to 0.1AAC
Input Power
71W
Input Voltage
120 to 277VAC
Intended LED Usage
LED Tubes
Length
9-1/2 in
Maximum Case Temperature
176 Degrees F
Number of Bulbs Supported
4
Ouput Constant
Constant Voltage
Output Current
0.25AAC
Output Technology
Fixed
Output Voltage
550VDC
Power Factor
0.92 to 0.99
Power Output
9 to 34W
Profile
Standard Profile
Total Harmonic Distortion (THD)
Max 15%
Width
1-5/16 in
