OEM#: DB-ANew OEM Original Outright
STANDARD-DUTY INDUSTRIAL FAN 375W by Patterson Fan Company, Inc.
Your price:
$1,303.06 each
OEM#: DB-ASTANDARD-DUTY INDUSTRIAL FAN 375W by Patterson Fan Company, Inc.
New OEM Original Outright
Your price:
$1,303.06 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: DB-A Key Specs
Item
STANDARD-DUTY INDUSTRIAL FAN 375W
OEM
Patterson Fan Company, Inc.
OEM #
DB-A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Air Flow
3,075 cfm
Air Velocity @ 10 Ft.
927 fpm
Air Velocity @ 20 Ft.
600 fpm
Air Velocity @ 40 Ft.
418 fpm
Amps
4.2
Assembly
Assembled
Bearing Type
Permanently Lubricated Ball
Color
Gray
Country of Origin
USA
Depth
18 5/16 in
Environmental Applications
Industrial
Fan Cord Length
No Cord
Fan Housing Material
Polypropylene
Fan Mounting Location
Ceiling
Fan Power Source
Hardwired
Height
12 1/8 in
Hz
60 Hz
Includes
Mounting Bracket
Length
35 in
Max. Ambient Temp.
104 Degrees F
Motor Design
Capacitor-Start/Run
Motor Enclosure
Totally Enclosed Non-Ventilated
Motor HP
1/2 hp
Motor Insulation
Class B
NEMA Plug Configuration
Hardwired
Number of Speeds
1
Oscillation
Non-Oscillating
Phase
1
RPM
1725
Sound Level
60 dBA
Thermal Protection
Automatic Reset
Voltage
120V AC
Watts
375
Wheel Dia.
6 in
Wheel Material
Steel
Width
35 in
