OEM#: TDX200S480DNew OEM Original Outright
SURGE PROTECTION DEVICE 480VAC DELTA 3PH by Nvent Erico
Your price:
$4,433.22 each
OEM#: TDX200S480DSURGE PROTECTION DEVICE 480VAC DELTA 3PH by Nvent Erico
New OEM Original Outright
Your price:
$4,433.22 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: TDX200S480D Key Specs
Item
SURGE PROTECTION DEVICE 480VAC DELTA 3PH
OEM
Nvent Erico
OEM #
TDX200S480D
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps
200 K
Basic Material
Metallic
Chase Nipple Size
3/4 in
Color
Gray
Country of Origin
China
Depth
3.07 in
Enclosure Material
Metal
Enclosure NEMA Rating
4
Filtering
No
IP Rating
65
Includes
Audible Alarm, Status Indicator Flag, Voltage Free Contact, Voltage Presence LED
Length
9.45 in
Lightning Impulse Current
25 kA
Max Continuing Operating Voltage
610/1220V AC
Max Operating Temperature
176 Degrees F
Max Surge Current per Mode
200kA
Max Surge Current per Phase
200 kA
Min Operating Temperature
-40 Degrees F
Modes of Protection
L-G, L-L
Modular
Yes
Mounting Location
Externally Mounted
Mounting Style
Chase Nipple/Panel
Nominal Discharge Current
20 kA
Number of Poles
3
Number of Wires
3 Wires + Ground
Phase
3
Short Circuit Current Rating
200kA
Standards
ANSI/IEEE, C-Tick, CE, IEC 61643-1, UL 1449 Edition 3 Type 1/2
System Connection
Parallel
UL SPD Type
Type 1/2
Voltage
480V AC Delta
Voltage Protection Rating
1800V (L-G, L-L)
Width
3.31 in
Wire Gauge
10 AWG
