OEM#: 031SA400O000030New OEM Original Outright
SOLENOID AIR CONTROL 1/8 120VAC by Numatics
Your price:
$192.54 each
OEM#: 031SA400O000030SOLENOID AIR CONTROL 1/8 120VAC by Numatics
New OEM Original Outright
Your price:
$192.54 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 031SA400O000030 Key Specs
Item
SOLENOID AIR CONTROL 1/8 120VAC
OEM
Numatics
OEM #
031SA400O000030
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp. Range
-10 Degrees to 115 Degrees F
Body Style
Body Ported
Coefficient of Volume
0.35
Electrical Connections
AC Hardwired w/15 in Leads
Max. CFM - Valves
16.0
NEMA Classification
NEMA 4
Operational Pressure Range
0 to 150 psi
Overall Height
2 1/8 in
Overall Length
3 1/4 in
Overall Width
7/8 in
Override
Non-Locking Flush
Pilot Port Size
1/8 in NPT
Pipe Size
1/8 in
Pneumatic Valves Product Group
Solenoid Air Control Valve
Power Consumption
4.0 W
Shifting Technology
Spool & Sleeve
Standards
CE, CSA, UL
Valve Actuator / Return
Solenoid / Spring
Valve Vacuum Range
0 to 28 in Hg
Valve Ways and Positions
4-Way/2-Position
Voltage
120V AC
