OEM#: SK172.1-71L/4 24.8New OEM Original Outright
AC GEARMOTOR 71 RPM TEFC 230/460V by Nord
Your price:
$1,358.59 each
OEM#: SK172.1-71L/4 24.8AC GEARMOTOR 71 RPM TEFC 230/460V by Nord
New OEM Original Outright
Your price:
$1,358.59 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: SK172.1-71L/4 24.8 Key Specs
Item
AC GEARMOTOR 71 RPM TEFC 230/460V
OEM
Nord
OEM #
SK172.1-71L/4 24.8
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Power Transmission
Bearings
Ball
Finish
Unpainted
Full Load Amps
1.90/0.95
Gear Case Material
Die Cast Aluminum Alloy
Gear Ratio
24.8:1
Gear Type
Helical
Gearmotor Brake Type
None
Gearmotor Enclosure
Totally Enclosed Fan-Cooled
Gearmotor Mounting Position
Horizontal
Gearmotor Phase
3
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Inline
Gearmotor Shaft Type
Single
Gearmotor Type
AC Gearmotor
Gears
Helical
Housing
Die Cast Aluminum Alloy
Hz
60 Hz
Input HP
1/2 hp
Insulation Class
F
Keyway Size Type
3/16 in x 3/32 in x 1-1/4 in
Length Less Shaft
13 7/20 in
Lubrication
Mineral Oil
Max. Ambient Temp.
40 Degrees C
Max. Torque
814.0 in-lb
Motor Type
3-Phase
Nameplate RPM
71 RPM
No Load RPM
71 RPM
Overhung Load
629 lb
RPM @ 50 Hz
59
Seals
Double Lip
Service Factor
1.8
Shaft Dia. (Dimension U)
3/4"
Shaft Length (Dimension V)
1.57"
Standards
UL Recognized, CSA Certified, CE Certified
Starting Torque
18 in-lb
