OEM#: FTN-C4E9ANew OEM Original Outright

STEAM TRAP 450F CAST IRON 0 TO 75 PSI by Nicholson

Your price:
$514.63 eachReady to ship
HomeNicholsonftnc4e9a
STEAM TRAP 450F CAST IRON 0 TO 75 PSI by Nicholson
STEAM TRAP 450F CAST IRON 0 TO 75 PSI by Nicholson

OEM#: FTN-C4E9A
STEAM TRAP 450F CAST IRON 0 TO 75 PSI by Nicholson

New OEM Original Outright
Your price:
$514.63 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: FTN-C4E9A Key Specs
Item
STEAM TRAP 450F CAST IRON 0 TO 75 PSI
OEM
Nicholson
OEM #
FTN-C4E9A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
(F)NPT Connections
1 in
Application
Blast Coils, Drains Steam Mains, Heat Exchangers and for all Process Applications Requiring Removal of Condensate as Quickly as it is Formed, Particularly when Controlled by Modulating Temperature or Pressure Control Valves, Unit Heaters
Body Material
Cast Iron
Condensate Capacity Lbs/Hr
1,450
Country of Origin
USA
Disc Material
Stainless Steel
Downstream PSI Range
0 to 75 psi
End to End Length
6 1/4 in
Max. Operating PSI
75 psi
Max. Temp.
450 Degrees F
NPT Inlet
1 in
NPT Outlet
1 in
Pipe Configuration
H Pattern
Pressure Air Vent
Self-Adjusting
Type
Float & Thermostatic
