OEM#: 52K3834New OEM Original Outright
250VAC 10A 10EH4/IEC MEDICAL QUICK CONNECT RFI POWER LINE FILTER by Newark / Element 14
Your price:
$30.06 each
OEM#: 52K3834250VAC 10A 10EH4/IEC MEDICAL QUICK CONNECT RFI POWER LINE FILTER by Newark / Element 14
New OEM Original Outright
Your price:
$30.06 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
- Minimal leakage current suitable for medical equipment
- Two element circuit provides basic EMI attenuation above 1 MHz
- Available with an internal ground circuit inductor (C suffix versions) to isolate equipment chassis from power line ground at radio frequencies
- Flanged mounting the same as the EC, ED and EF Series
- Capacitive output (see EAH, EBH and EJH Series for capacitive input)
- 10000pF capacitance
- 360µH minimum inductance
- 2250, 1450VDC line to ground, line to line
- 5µA, 2µ A leakage current maximum
Technical Specs
P/N: 52K3834 Key Specs
Item
250VAC 10A 10EH4/IEC MEDICAL QUICK CONNECT RFI POWER LINE FILTER
OEM
Newark / Element 14
OEM #
52K3834
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps
10A
Certifications
CSA, UL, VDE
Color
Black
Connector
10EH4/IEC
Frequency
50/60 HZ
Operating Temperature Range
-10°C - +40°C
Volts
250 VAC
Equivalents
- Minimal leakage current suitable for medical equipment
- Two element circuit provides basic EMI attenuation above 1 MHz
- Available with an internal ground circuit inductor (C suffix versions) to isolate equipment chassis from power line ground at radio frequencies
- Flanged mounting the same as the EC, ED and EF Series
- Capacitive output (see EAH, EBH and EJH Series for capacitive input)
- 10000pF capacitance
- 360µH minimum inductance
- 2250, 1450VDC line to ground, line to line
- 5µA, 2µ A leakage current maximum
- 52K3834: Datex-Ohmeda: Item Replacement
