OEM#: 510-110New OEM Original Outright
ELECTRICAL SAFETY ANALYZER by Netech Corp.
Your price:
$1,024.18 each $1,035.00 Savings: $10.82 (1%)
OEM#: 510-110ELECTRICAL SAFETY ANALYZER by Netech Corp.
New OEM Original Outright
Your price:
$1,024.18 each
$1,035.00 Savings: $10.82 (1%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Electrical Safety Analyzer, you’ll never have to worry about missing routine safety testing of your electrical equipment. Intentionally designed to be highly portable, you can always have it on hand. This analyzer was specifically created to test non-ECG equipment; all vital safety parameters – including ground resistance, leakage current, and instrument current - are conveniently displayed on its large LCD. Boasting unique operating features, provides you with a valuable combination of capabilities that outperform competing devices. Each device has calibrated test points that will ensure high accuracy of the instrument’s measurements. The accessible instrument fuse is also a seamless solution for the common maintenance problems of built-in fuses. Additionally, the selectable test load provides increased testing flexibility. You can be confident in the performance and value of the it because its meets both AMMI and IEC 601-1 Standards. It’s unquestionably the best option for your routine electrical safety testing.
Features
- Easy-to-use
- Fast, accurate, and portable
- Large LCD
- Accessible Line Fuse
- Selectable Test Loads
- Calibrated Test Points
- 15 and 20 Amp Capability
- Soft carrying case and red resistance test cables included
- Complies with AAMI or IEC 601-1 Test Loads
Technical Specs
P/N: 510-110 Key Specs
Item
ELECTRICAL SAFETY ANALYZER
OEM
Netech Corp.
OEM #
510-110
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Accuracy
Resistance: ± 2% ± 1 LSD; Leakage: ± 1% FS DC to 1 kHz ± 1 LSD ± 2 % FS DC 1 kHz to 100 kHz ± 4% FS 100 kHz to 1 MHz; Instrument Current: ± 2% ± 1 LSD
Dimensions
6 in x 3.25 in x 2.25 in
Display
LCD 3 1/2 digits
Measurement Range
Resistance: 0 -1999 Milli Ohms; Leakage Current: 0 - 1999 uA; Instrument Current: 0 - 19.99 A
Measures
Ground Resistance; Leakage Current; Instrument Current
Operating Voltage
110 VAC or 220 VAC
Weight
1 lb
