OEM#: 5208-2NSNew OEM Original Outright
DOUBLE ROW ANGULAR CONTACT BEARING, DOUBLE SEALED, 40MM BORE X 80MM OD X 30.2MM W by Nachi America Inc
Your price:
$148.16 each
OEM#: 5208-2NSDOUBLE ROW ANGULAR CONTACT BEARING, DOUBLE SEALED, 40MM BORE X 80MM OD X 30.2MM W by Nachi America Inc
New OEM Original Outright
Your price:
$148.16 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
NACHI 5208-2NS, Double Row Angular Contact Bearing, Double Sealed, 40MM Bore x 80MM OD x 30.2MM W
Double Row Angular Contact Ball Bearings are functionally same as two single row angular contact ball bearings mounted back-to-back except they have only one inner ring and one outer ring. These bearings take heavy radial loads, and axial loads equally in either direction.
Double Row Angular Contact Ball Bearings are functionally same as two single row angular contact ball bearings mounted back-to-back except they have only one inner ring and one outer ring. These bearings take heavy radial loads, and axial loads equally in either direction.
Technical Specs
P/N: 5208-2NS Key Specs
Item
DOUBLE ROW ANGULAR CONTACT BEARING, DOUBLE SEALED, 40MM BORE X 80MM OD X 30.2MM W
OEM
Nachi America Inc
OEM #
5208-2NS
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bore Diameter Millimeters
40
Contact Angle (Degrees)
20°
Country of Origin
Japan
Dynamic Load Rating (N)
45500
Max Speed (Rpm) / Grease
6,000
Outer Diameter Millimeters
80
Radial Clearance
Normal
Series
5200
Static Load Rating (N)
34000
Tolerance
ISO Class 0
Width Millimeters
30.2
NACHI 5208-2NS, Double Row Angular Contact Bearing, Double Sealed, 40MM Bore x 80MM OD x 30.2MM W
Double Row Angular Contact Ball Bearings are functionally same as two single row angular contact ball bearings mounted back-to-back except they have only one inner ring and one outer ring. These bearings take heavy radial loads, and axial loads equally in either direction.
Double Row Angular Contact Ball Bearings are functionally same as two single row angular contact ball bearings mounted back-to-back except they have only one inner ring and one outer ring. These bearings take heavy radial loads, and axial loads equally in either direction.
