OEM#: 5203-2NSNew OEM Original Outright
5203-2NS, DBL ROW ANGULAR CONTACT BEARING, DBL SEAL, 17MM BORE X 40MM OD X 17.5MM W-MIN QTY 3 by Nachi America Inc
Your price:
$55.07 each
OEM#: 5203-2NS5203-2NS, DBL ROW ANGULAR CONTACT BEARING, DBL SEAL, 17MM BORE X 40MM OD X 17.5MM W-MIN QTY 3 by Nachi America Inc
New OEM Original Outright
Your price:
$55.07 each
Asset Information
Must purchase minimum of 3
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
NACHI 5203-2NS, Double Row Angular Contact Bearing, Double Sealed, 17MM Bore x 40MM OD x 17.5MM W
Double Row Angular Contact Ball Bearings are functionally same as two single row angular contact ball bearings mounted back-to-back except they have only one inner ring and one outer ring. These bearings take heavy radial loads, and axial loads equally in either direction.
Double Row Angular Contact Ball Bearings are functionally same as two single row angular contact ball bearings mounted back-to-back except they have only one inner ring and one outer ring. These bearings take heavy radial loads, and axial loads equally in either direction.
Technical Specs
P/N: 5203-2NS Key Specs
Item
5203-2NS, DBL ROW ANGULAR CONTACT BEARING, DBL SEAL, 17MM BORE X 40MM OD X 17.5MM W-MIN QTY 3
OEM
Nachi America Inc
OEM #
5203-2NS
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bore Diameter (mm)
17
Contact Angle (degrees)
20°
Country of Origin
Japan
Dynamic Load Rating (N)
15000
Maximum Speed (RPM) (Grease)
12,000
Outside Diameter (mm)
40
Radial Clearance
Normal
Series
5200
Static Load Rating (N)
9250
Tolerance
ISO Class 0
Width (mm)
17.5
NACHI 5203-2NS, Double Row Angular Contact Bearing, Double Sealed, 17MM Bore x 40MM OD x 17.5MM W
Double Row Angular Contact Ball Bearings are functionally same as two single row angular contact ball bearings mounted back-to-back except they have only one inner ring and one outer ring. These bearings take heavy radial loads, and axial loads equally in either direction.
Double Row Angular Contact Ball Bearings are functionally same as two single row angular contact ball bearings mounted back-to-back except they have only one inner ring and one outer ring. These bearings take heavy radial loads, and axial loads equally in either direction.
