OEM#: 50TAB10UP4New OEM Original Outright
BALL SCREW SUPPORT BEARING, SINGLE, FLUSH GROUND, 50MM BORE, 100MM OD by Nachi America Inc
Your price:
$552.05 each
OEM#: 50TAB10UP4BALL SCREW SUPPORT BEARING, SINGLE, FLUSH GROUND, 50MM BORE, 100MM OD by Nachi America Inc
New OEM Original Outright
Your price:
$552.05 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
NACHI Ball Screw Support Bearing 50TAB10UP4, Single, Flush Ground, 50MM Bore, 100MM OD
Features
When single flush ground bearing (suffix U) is assembled in duplex and axial load is applied to 2 rows or 3 rows, load rating listed is to be multiplied by 1.62 or 2.16 respectively for Dynamic and multiplied by 2 or 3 respectively for Axial Limiting Load.
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
When single flush ground bearing (suffix U) is assembled in duplex and axial load is applied to 2 rows or 3 rows, load rating listed is to be multiplied by 1.62 or 2.16 respectively for Dynamic and multiplied by 2 or 3 respectively for Axial Limiting Load.
Technical Specs
P/N: 50TAB10UP4 Key Specs
Item
BALL SCREW SUPPORT BEARING, SINGLE, FLUSH GROUND, 50MM BORE, 100MM OD
OEM
Nachi America Inc
OEM #
50TAB10UP4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Axial Limiting Load (N)
119,000
Bearing Style
Flush Ground
Bore Diameter Millimeters
50
Cage Type
Polyamide Resin
Contact Angle (Degrees)
60°
Country of Origin
Japan
Dynamic Load Rating (N)
69,500
Max Speed (Rpm) / Grease
2,700
Max Speed / Oil (Rpm)
3,500
Outer Diameter Millimeters
100
Preload
Medium
Tolerance
ISO P4
Width Millimeters
20
NACHI Ball Screw Support Bearing 50TAB10UP4, Single, Flush Ground, 50MM Bore, 100MM OD
Features
When single flush ground bearing (suffix U) is assembled in duplex and axial load is applied to 2 rows or 3 rows, load rating listed is to be multiplied by 1.62 or 2.16 respectively for Dynamic and multiplied by 2 or 3 respectively for Axial Limiting Load.
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
When single flush ground bearing (suffix U) is assembled in duplex and axial load is applied to 2 rows or 3 rows, load rating listed is to be multiplied by 1.62 or 2.16 respectively for Dynamic and multiplied by 2 or 3 respectively for Axial Limiting Load.
