OEM#: 30TAB06DF-2LR/GMP4New OEM Original Outright
BALL SCREW SUPPORT BEARING, DUPLEX, FACE-TO-FACE, 30MM BORE, 62MM OD by Nachi America Inc
Your price:
$718.19 each
OEM#: 30TAB06DF-2LR/GMP4BALL SCREW SUPPORT BEARING, DUPLEX, FACE-TO-FACE, 30MM BORE, 62MM OD by Nachi America Inc
New OEM Original Outright
Your price:
$718.19 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
NACHI Ball Screw Support Bearing 30TAB06DF-2LR/GMP4, Duplex, Face-To-Face, 30MM Bore, 62MM OD
Features
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
Technical Specs
P/N: 30TAB06DF-2LR/GMP4 Key Specs
Item
BALL SCREW SUPPORT BEARING, DUPLEX, FACE-TO-FACE, 30MM BORE, 62MM OD
OEM
Nachi America Inc
OEM #
30TAB06DF-2LR/GMP4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Axial Limiting Load (N)
92,800
Bearing Style
Face-To-Face, Double Sealed
Bore Diameter Millimeters
30
Cage Type
Polyamide Resin
Contact Angle (Degrees)
60°
Country of Origin
Japan
Dynamic Load Rating (N)
48,438
Max Speed (Rpm) / Grease
4,650
Outer Diameter Millimeters
62
Preload
Medium
Tolerance
ISO P4
Width Millimeters
15
NACHI Ball Screw Support Bearing 30TAB06DF-2LR/GMP4, Duplex, Face-To-Face, 30MM Bore, 62MM OD
Features
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
Product Overview
NACHI Ball Screw Support Bearing 30TAB06DF-2LR/GMP4, Duplex, Face-To-Face, 30MM Bore, 62MM OD
Features
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
Technical Specs
P/N: 30TAB06DF-2LR/GMP4 Key Specs
Item
BALL SCREW SUPPORT BEARING, DUPLEX, FACE-TO-FACE, 30MM BORE, 62MM OD
OEM
Nachi America Inc
OEM #
30TAB06DF-2LR/GMP4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Axial Limiting Load (N)
92,800
Bearing Style
Face-To-Face, Double Sealed
Bore Diameter Millimeters
30
Cage Type
Polyamide Resin
Contact Angle (Degrees)
60°
Country of Origin
Japan
Dynamic Load Rating (N)
48,438
Max Speed (Rpm) / Grease
4,650
Outer Diameter Millimeters
62
Preload
Medium
Tolerance
ISO P4
Width Millimeters
15
NACHI Ball Screw Support Bearing 30TAB06DF-2LR/GMP4, Duplex, Face-To-Face, 30MM Bore, 62MM OD
Features
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
Product Overview
NACHI Ball Screw Support Bearing 30TAB06DF-2LR/GMP4, Duplex, Face-To-Face, 30MM Bore, 62MM OD
Features
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
Technical Specs
P/N: 30TAB06DF-2LR/GMP4 Key Specs
Item
BALL SCREW SUPPORT BEARING, DUPLEX, FACE-TO-FACE, 30MM BORE, 62MM OD
OEM
Nachi America Inc
OEM #
30TAB06DF-2LR/GMP4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Axial Limiting Load (N)
92,800
Bearing Style
Face-To-Face, Double Sealed
Bore Diameter Millimeters
30
Cage Type
Polyamide Resin
Contact Angle (Degrees)
60°
Country of Origin
Japan
Dynamic Load Rating (N)
48,438
Max Speed (Rpm) / Grease
4,650
Outer Diameter Millimeters
62
Preload
Medium
Tolerance
ISO P4
Width Millimeters
15
NACHI Ball Screw Support Bearing 30TAB06DF-2LR/GMP4, Duplex, Face-To-Face, 30MM Bore, 62MM OD
Features
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
