OEM#: 22309EXQW33C3New OEM Original Outright
DOUBLE ROW SPHERICAL ROLLER BEARING 22309EXW33C3, 45MM BORE, 100MM OD by Nachi America Inc
Your price:
$213.71 each
OEM#: 22309EXQW33C3DOUBLE ROW SPHERICAL ROLLER BEARING 22309EXW33C3, 45MM BORE, 100MM OD by Nachi America Inc
New OEM Original Outright
Your price:
$213.71 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
NACHI Double Row Spherical Roller Bearing 22309EXW33C3, 45MM Bore, 100MM OD
NACHI Features
- NACHI spherical roller bearings can sustain both heavy radial and axial loads in either direction
- Deflection of shaft, housing, or misalignment of axes can be automatically corrected by self-aligning feature which prevents the application of excessive force
- NACHI's newly developed heat stabilization process can sustain normal function in operating temperatures of up to 200°C (392°F) with minimal dimensional changes and no reduction of bearing life
- Maximum permissible misalignment angle is approximately 2° under general service conditions
Technical Specs
P/N: 22309EXQW33C3 Key Specs
Item
DOUBLE ROW SPHERICAL ROLLER BEARING 22309EXW33C3, 45MM BORE, 100MM OD
OEM
Nachi America Inc
OEM #
22309EXQW33C3
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bore Diameter Millimeters
45
Country of Origin
Japan
Dynamic Load Rating (N)
230,000
Max Speed / Oil (Rpm)
5600
Outer Diameter Millimeters
100
Static Load Rating (N)
182,000
Width Millimeters
36
NACHI Double Row Spherical Roller Bearing 22309EXW33C3, 45MM Bore, 100MM OD
NACHI Features
- NACHI spherical roller bearings can sustain both heavy radial and axial loads in either direction
- Deflection of shaft, housing, or misalignment of axes can be automatically corrected by self-aligning feature which prevents the application of excessive force
- NACHI's newly developed heat stabilization process can sustain normal function in operating temperatures of up to 200°C (392°F) with minimal dimensional changes and no reduction of bearing life
- Maximum permissible misalignment angle is approximately 2° under general service conditions
