OEM#: 20TAB04UP4New OEM Original Outright
BALL SCREW SUPPORT BEARING, SINGLE, FLUSH GROUND, 20MM BORE, 47MM OD by Nachi America Inc
Your price:
$269.70 each
OEM#: 20TAB04UP4BALL SCREW SUPPORT BEARING, SINGLE, FLUSH GROUND, 20MM BORE, 47MM OD by Nachi America Inc
New OEM Original Outright
Your price:
$269.70 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
NACHI Ball Screw Support Bearing 20TAB04UP4, Single, Flush Ground, 20MM Bore, 47MM OD
Features
When single flush ground bearing (suffix U) is assembled in duplex and axial load is applied to 2 rows or 3 rows, load rating listed is to be multiplied by 1.62 or 2.16 respectively for Dynamic and multiplied by 2 or 3 respectively for Axial Limiting Load.
Features
- These bearings are designed to support ball screws that are used as actuators of high precision and high speed machines
- Their stiffness is much greater than conventional angular contact ball bearings as these have a greater number of balls
- These bearings are supplied with a pre-set preload to eliminate complicated adjustment and torque measurement
- Flush ground bearings (suffix DU or U) can be used in DB (back to back), DF (face to face) or DT (tandem) assembly
When single flush ground bearing (suffix U) is assembled in duplex and axial load is applied to 2 rows or 3 rows, load rating listed is to be multiplied by 1.62 or 2.16 respectively for Dynamic and multiplied by 2 or 3 respectively for Axial Limiting Load.
Technical Specs
P/N: 20TAB04UP4 Key Specs
Item
BALL SCREW SUPPORT BEARING, SINGLE, FLUSH GROUND, 20MM BORE, 47MM OD
OEM
Nachi America Inc
OEM #
20TAB04UP4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Axial Limiting Load (N)
32,000
Bearing Style
Flush Ground
Bore Diameter Millimeters
20
Cage Type
Polyamide Resin
Contact Angle (Degrees)
60°
Country of Origin
Japan
Dynamic Load Rating (N)
25,900
Max Speed (Rpm) / Grease
6,300
Max Speed / Oil (Rpm)
8,000
Outer Diameter Millimeters
47
Preload
Medium
Tolerance
ISO P4
Width Millimeters
15
NACHI Ball Screw Support Bearing 20TAB04UP4, Single, Flush Ground, 20MM Bore, 47MM OD
