TEST LED, STIMULUS by Micropace
OEM#: MP3058TEST LED, STIMULUS by Micropace
This is a helpful test jig consisting of a yellow and a red LED wired in parallel and terminated in a red(+ve) and a black(-ve) 2mm banana plug. It may be useful in testing for the presence of stimulus output at the Stimulus Multiplexer Box or at the patient interface connector. Connect red plug to positive and black plug to negative pacing output terminals. Pace at 10mA to 20mA for brighter indication. Yellow LED flashes when pacing with correct polarity; red LED flashes when pacing but with incorrect polarity.
