OEM#: 46-830NNew OEM Original Outright

STEAM TRAP 2 NPT OUTLET SS DISC by Mepco

Your price:
$736.51 eachReady to ship
HomeMepco46830n
STEAM TRAP 2 NPT OUTLET SS DISC by Mepco
STEAM TRAP 2 NPT OUTLET SS DISC by Mepco

OEM#: 46-830N
STEAM TRAP 2 NPT OUTLET SS DISC by Mepco

New OEM Original Outright
Your price:
$736.51 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 46-830N Key Specs
Item
STEAM TRAP 2 NPT OUTLET SS DISC
OEM
Mepco
OEM #
46-830N
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
(F)NPT Connections
2 in
Application
Steam
Body Material
Cast Iron
Condensate Capacity Lbs/Hr
12,500
Country of Origin
USA
Disc Material
Stainless Steel
Downstream PSI Range
0 to 25 psi
End to End Length
7 in
Max Operating PSI
30 psi
Max Temperature
450 Degrees F
NPT Inlet
2 in
NPT Outlet
2 in
NPT Port
2 in
Pipe Configuration
(2) Pipe, (1) Inlet and (1) Outlet
Pressure Air Vent
Releases Air and Non-Condensable Gases That Adversely Affect The Heat Transfer of A Steam System
Trap Position
Horizontal
Type
Float and Thermostatic
