OEM#: U269New OEM Original Outright

PREMIUM EFFICIENCY MOTOR, 5HP, 1200RPM, 208-230/460V, 3PH, 215T FR, DP by Marathon Motors

Your price:
$309.48 each
$1,134.00 Savings: $824.52 (73%)
Ready to ship
HomeMarathon Motorsu269
PREMIUM EFFICIENCY MOTOR, 5HP, 1200RPM, 208-230/460V, 3PH, 215T FR, DP by Marathon Motors
PREMIUM EFFICIENCY MOTOR, 5HP, 1200RPM, 208-230/460V, 3PH, 215T FR, DP by Marathon Motors

OEM#: U269
PREMIUM EFFICIENCY MOTOR, 5HP, 1200RPM, 208-230/460V, 3PH, 215T FR, DP by Marathon Motors

New OEM Original Outright
Your price:
$309.48 each
$1,134.00 Savings: $824.52 (73%)
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

Marathon Motors Premium Efficiency Motor, U269, 5HP, 1200RPM, 208-230/460V, 3PH, 215T FR, DP

Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.

Technical Specs
P/N: U269 Key Specs
Item
PREMIUM EFFICIENCY MOTOR, 5HP, 1200RPM, 208-230/460V, 3PH, 215T FR, DP
OEM
Marathon Motors
OEM #
U269
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
18/9
50 Hertz Fl Eff
88.50 Percent
50 Hertz Hp
5
50 Hertz Kw
3.7
50 Hertz Rpm
1000
50 Hertz Sf
1.15
50 Hertz Voltage
200/400
60 Hertz Kw
3.7
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
Ball
Bearing-Opp-Drive-End
Ball
Csa
Y
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
15.8-15/7.5
Fl Efficiency
90.2
Frame
215T
Horsepower
5
Insulation Class
F
Ip Code
22
Is_Motor
Yes
Kva-Code
J
Model Number
215TTDC6076
Motor Rpm 60Hz
1200
Mounting
Rigid
Nameplate Rpm
1200
Nema Design
B
Orientation
Horizontal
Phase
3
Rpm Range
1101-1200
Service Factor
1.15
Starting Type
Across The Line
Ul
Recognized Construction
Voltage
208-230/460
Weight
185

Marathon Motors Premium Efficiency Motor, U269, 5HP, 1200RPM, 208-230/460V, 3PH, 215T FR, DP

Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
