OEM#: O214New OEM Original Outright
OIL BURNER MOTOR, 56C34D2104, 3/4HP, 3600RPM, 115/208-230V, 1PH, 56C, DP by Marathon Motors
Your price:
$285.33 each
OEM#: O214OIL BURNER MOTOR, 56C34D2104, 3/4HP, 3600RPM, 115/208-230V, 1PH, 56C, DP by Marathon Motors
New OEM Original Outright
Your price:
$285.33 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Oil Burner Motor, O214, 56C34D2104, 3/4HP, 3600RPM, 115/208-230V, 1PH, 56C, DP
Direct Replacement motors for residential and commercial oil burners and hot water pressure/steam cleaners. Voltage available is 115/230 Vac, Single Phase. Horsepower Range from Stock is 1/4 - 3. Rpm is 3600.
Direct Replacement motors for residential and commercial oil burners and hot water pressure/steam cleaners. Voltage available is 115/230 Vac, Single Phase. Horsepower Range from Stock is 1/4 - 3. Rpm is 3600.
Technical Specs
P/N: O214 Key Specs
Item
OIL BURNER MOTOR, 56C34D2104, 3/4HP, 3600RPM, 115/208-230V, 1PH, 56C, DP
OEM
Marathon Motors
OEM #
O214
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Assembly
F1 Only
Bearing Type
Ball
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
9.8/4.8-4.9
Frame
56C
Hertz
50
Horsepower
3/4
Insulation Class
B
Is_Motor
Yes
Motor Rpm 60Hz
3600
Mounting
RD (Round)
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Phase
1
Rated Rpm
3600
Rotation
CCW
Rpm Range
3001-3600
Service Factor
1.5
Speeds
1
Thermal Protection
Manual
Voltage
115/208-230
Weight Lbs
20
Marathon Motors Oil Burner Motor, O214, 56C34D2104, 3/4HP, 3600RPM, 115/208-230V, 1PH, 56C, DP
Direct Replacement motors for residential and commercial oil burners and hot water pressure/steam cleaners. Voltage available is 115/230 Vac, Single Phase. Horsepower Range from Stock is 1/4 - 3. Rpm is 3600.
Direct Replacement motors for residential and commercial oil burners and hot water pressure/steam cleaners. Voltage available is 115/230 Vac, Single Phase. Horsepower Range from Stock is 1/4 - 3. Rpm is 3600.
