OEM#: HG714New OEM Original Outright
CARBONATOR PUMP MOTOR, 3/4HP, 115/230V, 1800RPM, SPLIT PH, 48Y FR, DP by Marathon Motors
Your price:
$549.54 each
OEM#: HG714CARBONATOR PUMP MOTOR, 3/4HP, 115/230V, 1800RPM, SPLIT PH, 48Y FR, DP by Marathon Motors
New OEM Original Outright
Your price:
$549.54 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Carbonator Pump Motor, HG714, 3/4HP, 115/230V, 1800RPM, Split PH, 48Y FR, DP
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
Technical Specs
P/N: HG714 Key Specs
Item
CARBONATOR PUMP MOTOR, 3/4HP, 115/230V, 1800RPM, SPLIT PH, 48Y FR, DP
OEM
Marathon Motors
OEM #
HG714
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Rpms
1800
Ambient Temp C
40
Bearing-Drive-End
6203
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
10.4/5.2
Fl Efficiency
0
Frame
48Y
Horsepower
3/4
Insulation Class
B
Is_Motor
Yes
Kva-Code
L
Model Number
5KH37PNA479X
Motor Rpm 60Hz
1800
Mounting
Resilient Base
Opposite End Bearing
6203
Opposite End Bearing Size
6203
Orientation
Horizontal or Vertical
Phase
1
Rotation
CCW
Rpm
1800
Rpm Range
1701-1800
Service Factor
1
Starting Type
Switch and Mech
Thermal Protection
Automatic
Ul
Y
Voltage
115/230
Weight
22
Marathon Motors Carbonator Pump Motor, HG714, 3/4HP, 115/230V, 1800RPM, Split PH, 48Y FR, DP
