Product Overview
Marathon Motors Explosion Proof Motor, HG458, 5KH36PNB171X, 1/4HP, 115V, 3600RPM, 1PH, EPNV
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: HG458 Key Specs
Item
EXPLOSION PROOF MOTOR, 5KH36PNB171X, 1/4HP, 115V, 3600RPM, 1PH, EPNV
OEM
Marathon Motors
OEM #
HG458
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.19
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
Ball
Ce
N
Duty
Continuous
Enclosure
EPNV
Enclosure Type
Explosion Proof
Fl Amps
4.4
Fl Efficiency
59.5
Frame
48
Hazardous Location
EXP PROOF CL I GR D CL II GR F&G T3B
Hertz
60
Horsepower
1/4
Insulation Class
A
Ip Code
54
Is_Motor
Yes
Kva-Code
N
Model Number
5KH36PNB171X
Motor Rpm 60Hz
3600
Mounting
Rigid
Nema Design
No Design Code
Opposite End Bearing
Ball
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
3600
Rpm Range
3001-3600
Service Factor
1
Starting Type
Spilt Phase
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
115
Weight
23.5
