OEM#: E261ANew OEM Original Outright
5KCR46MN0090X, 1/2HP, 1800/1500, 100-120/200-240V, 1PH, 56C FR, DP by Marathon Motors
Your price:
$558.74 each $615.00 Savings: $56.26 (9%)
OEM#: E261A5KCR46MN0090X, 1/2HP, 1800/1500, 100-120/200-240V, 1PH, 56C FR, DP by Marathon Motors
New OEM Original Outright
Your price:
$558.74 each
$615.00 Savings: $56.26 (9%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors, E261A, 5KCR46MN0090X, 1/2HP, 1800/1500RPM, 100-120/200-240V, 1PH, 56C FR, DP
Marathon's Single Phase extensive line of General Purpose motors are available in ODP and TEFC construction, Foot Mounted and Footless. Horsepower sizes available from stock range from 1/12 HP through 15 HP.
Marathon's Single Phase extensive line of General Purpose motors are available in ODP and TEFC construction, Foot Mounted and Footless. Horsepower sizes available from stock range from 1/12 HP through 15 HP.
Technical Specs
P/N: E261A Key Specs
Item
5KCR46MN0090X, 1/2HP, 1800/1500, 100-120/200-240V, 1PH, 56C FR, DP
OEM
Marathon Motors
OEM #
E261A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6203
Bearing-Opp-Drive-End
6203
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
5.8-5.6/2.9-2.8
Frame
56C
Horsepower
1/2
Insulation Class
B
Is_Motor
Yes
Kva-Code
N
Model Number
5KCR46MN0090X
Motor Rpm 50Hz
1500
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nameplate Rpm
1800/1500
Opposite End Bearing Size
6203
Orientation
Horizontal or Vertical
Phase
1
Rotation
CCW
Rpm Range
1701-1800
Service Factor
1.25
Starting Type
Switch and Mech
Thermal Protection
Automatic
Ul
Y
Voltage
120/240
Weight
25
Marathon Motors, E261A, 5KCR46MN0090X, 1/2HP, 1800/1500RPM, 100-120/200-240V, 1PH, 56C FR, DP
Marathon's Single Phase extensive line of General Purpose motors are available in ODP and TEFC construction, Foot Mounted and Footless. Horsepower sizes available from stock range from 1/12 HP through 15 HP.
Marathon's Single Phase extensive line of General Purpose motors are available in ODP and TEFC construction, Foot Mounted and Footless. Horsepower sizes available from stock range from 1/12 HP through 15 HP.
