OEM#: E247New OEM Original Outright
PREMIUM EFFICIENCY MOTOR, 200HP, 1800RPM, 460V, 3PH, 445T FR, TEFC by Marathon Motors
Your price:
$23,507.65 each
OEM#: E247PREMIUM EFFICIENCY MOTOR, 200HP, 1800RPM, 460V, 3PH, 445T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$23,507.65 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Premium Efficiency Motor, E247, 200HP, 1800RPM, 460V, 3PH, 445T FR, TEFC
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Technical Specs
P/N: E247 Key Specs
Item
PREMIUM EFFICIENCY MOTOR, 200HP, 1800RPM, 460V, 3PH, 445T FR, TEFC
OEM
Marathon Motors
OEM #
E247
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
149
Ambient Temp C
40
Approval-Ce
Y
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
NU318
Bearing-Opp-Drive-End
6316
Country of Origin
USA
Csa
Y
Drive End Bearing Size
NU318
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
226
Fl Efficiency
96.2
Frame
445T
Horsepower
200
Insulation Class
F
Ip Code
43
Is_Motor
Yes
Kva-Code
G
Model Number
445TTFN6038
Motor Rpm 60Hz
1800
Mounting
Rigid
Nameplate Rpm
1800
Nema Design
B
Opposite End Bearing Size
6316
Orientation
Horizontal
Phase
3
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Across The Line
Ul
Recognized Construction
Voltage
460
Weight
2604
