OEM#: Y980New OEM Original Outright
INVERTER DUTY MOTOR, 182THES8048, 3HP, 230/460V, 1800RPM, 3PH, 182TC, EPNV by Marathon Motors
Your price:
$8,942.75 each
OEM#: Y980INVERTER DUTY MOTOR, 182THES8048, 3HP, 230/460V, 1800RPM, 3PH, 182TC, EPNV by Marathon Motors
New OEM Original Outright
Your price:
$8,942.75 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y980, 182THES8048, 3HP, 230/460V, 1800RPM, 3PH, 182TC, EPNV
Designed for industrial applications with Vector Drives where up to a 2000:1 constant torque speed range is required. Used in dirty, dusty or caustic environments where cast iron construction is required, and installed in hazardous environments.
Designed for industrial applications with Vector Drives where up to a 2000:1 constant torque speed range is required. Used in dirty, dusty or caustic environments where cast iron construction is required, and installed in hazardous environments.
Technical Specs
P/N: Y980 Key Specs
Item
INVERTER DUTY MOTOR, 182THES8048, 3HP, 230/460V, 1800RPM, 3PH, 182TC, EPNV
OEM
Marathon Motors
OEM #
Y980
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
8.2/4.1
60 Hertz Fl Eff
84.00 Percent
60 Hertz Kw
2.24
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
Ball
Catalog No.
Y980
Ce
N
Country of Origin
USA
Drive End Bearing Size
6207
Duty
Continuous
Enclosure
EPNV
Enclosure Type
Explosion Proof
Frame
182TC
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3C
Horsepower
3
Insulation Class
F
Inverter Speed Range
Constant 2000:1
Ip Code
54
Is_Motor
Yes
Kva-Code
L
Model Number
182THES8048
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6206
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
UL Listed
Voltage
230/460
Weight In Lbs.
117
