OEM#: Y578New OEM Original Outright
INVERTER DUTY MOTOR, 445THFN8040, 200HP, 460V, 1800RPM, 3PH, 445T, TEFC by Marathon Motors
Your price:
$35,941.04 each
OEM#: Y578INVERTER DUTY MOTOR, 445THFN8040, 200HP, 460V, 1800RPM, 3PH, 445T, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$35,941.04 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y578, 445THFN8040, 200HP, 460V, 1800RPM, 3PH, 445T, TEFC
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Technical Specs
P/N: Y578 Key Specs
Item
INVERTER DUTY MOTOR, 445THFN8040, 200HP, 460V, 1800RPM, 3PH, 445T, TEFC
OEM
Marathon Motors
OEM #
Y578
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
230
60 Hertz Fl Eff
95.00 Percent
60 Hertz Kw
149
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
Ball
Catalog No.
Y578
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6318
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
445T
Horsepower
200
Insulation Class
H
Inverter Speed Range
Constant 2000:1
Ip Code
43
Is_Motor
Yes
Kva-Code
K
Model Number
445THFN8040
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6316
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
Recognized Construction
Voltage
460
Weight In Lbs.
2388
Marathon Motors Inverter Duty Motor, Y578, 445THFN8040, 200HP, 460V, 1800RPM, 3PH, 445T, TEFC
