OEM#: Y565New OEM Original Outright
INVERTER DUTY MOTOR, 213THTS8038, 7.5HP, 230/460V, 1800RPM, 3PH, 213TC, TENV by Marathon Motors
Your price:
$3,043.01 each
OEM#: Y565INVERTER DUTY MOTOR, 213THTS8038, 7.5HP, 230/460V, 1800RPM, 3PH, 213TC, TENV by Marathon Motors
New OEM Original Outright
Your price:
$3,043.01 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y565, 213THTS8038, 7.5HP, 230/460V, 1800RPM, 3PH, 213TC, TENV
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Technical Specs
P/N: Y565 Key Specs
Item
INVERTER DUTY MOTOR, 213THTS8038, 7.5HP, 230/460V, 1800RPM, 3PH, 213TC, TENV
OEM
Marathon Motors
OEM #
Y565
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
21/10.5
60 Hertz Fl Eff
90.20 Percent
60 Hertz Kw
5.6
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
Ball
Catalog No.
Y565
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6309
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Frame
213TC
Horsepower
7 1/2
Insulation Class
H
Inverter Speed Range
Constant 2000:1
Ip Code
43
Is_Motor
Yes
Kva-Code
L
Model Number
213THTS8038
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6207
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
Recognized Construction and Protector
Voltage
230/460
Weight In Lbs.
212
Marathon Motors Inverter Duty Motor, Y565, 213THTS8038, 7.5HP, 230/460V, 1800RPM, 3PH, 213TC, TENV
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
