OEM#: Y555New OEM Original Outright
INVERTER DUTY MOTOR, 56H17T5311, 1/2HP, 575V, 1800RPM, 3PH, 56C, TENV by Marathon Motors
Your price:
$762.24 each
OEM#: Y555INVERTER DUTY MOTOR, 56H17T5311, 1/2HP, 575V, 1800RPM, 3PH, 56C, TENV by Marathon Motors
New OEM Original Outright
Your price:
$762.24 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y555, 56H17T5311, 1/2HP, 575V, 1800RPM, 3PH, 56C, TENV
Designed for inverter or vector applications where up to a 1000:1 constant Torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps, compressors, textile processing and other industrial machinery installed in dusty or dirty environments.
Designed for inverter or vector applications where up to a 1000:1 constant Torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps, compressors, textile processing and other industrial machinery installed in dusty or dirty environments.
Technical Specs
P/N: Y555 Key Specs
Item
INVERTER DUTY MOTOR, 56H17T5311, 1/2HP, 575V, 1800RPM, 3PH, 56C, TENV
OEM
Marathon Motors
OEM #
Y555
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
0.64
60 Hertz Fl Eff
80.00 Percent
60 Hertz Kw
0.37
60 Hertz Sf
1.0
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
Ball
Catalog No.
Y555
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Frame
56C
Horsepower
1/2
Insulation Class
F
Inverter Speed Range
Constant 1000:1
Ip Code
43
Is_Motor
Yes
Kva-Code
L
Model Number
56H17T5311
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
Recognized Construction and Protector
Voltage
575
Weight In Lbs.
35
Marathon Motors Inverter Duty Motor, Y555, 56H17T5311, 1/2HP, 575V, 1800RPM, 3PH, 56C, TENV
Designed for inverter or vector applications where up to a 1000:1 constant Torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps, compressors, textile processing and other industrial machinery installed in dusty or dirty environments.
Designed for inverter or vector applications where up to a 1000:1 constant Torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps, compressors, textile processing and other industrial machinery installed in dusty or dirty environments.
