OEM#: Y532New OEM Original Outright
INVERTER DUTY MOTOR, 449THFS8047, 300HP, 460V, 1800RPM, 3PH, 449T, TEBC by Marathon Motors
Your price:
$67,567.40 each
OEM#: Y532INVERTER DUTY MOTOR, 449THFS8047, 300HP, 460V, 1800RPM, 3PH, 449T, TEBC by Marathon Motors
New OEM Original Outright
Your price:
$67,567.40 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y532, 449THFS8047, 300HP, 460V, 1800RPM, 3PH, 449T, TEBC
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Technical Specs
P/N: Y532 Key Specs
Item
INVERTER DUTY MOTOR, 449THFS8047, 300HP, 460V, 1800RPM, 3PH, 449T, TEBC
OEM
Marathon Motors
OEM #
Y532
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz FL Amps
327
60 Hertz FL Eff
95.40 Percent
60 Hertz SF
1
60 Hertz kW
224
Ambient Temperature (°C)
40
Assembly
F1 (F2 Modification Available)
Bearing Drive End
Ball
CE
Y
CSA
Y
Catalog Number
Y532
Country of Origin
USA
Drive End Bearing Size
6319
Duty
Continuous
Enclosure
TEBC
Enclosure Type
Totally Enclosed
Frame
449T
Horsepower
300
IP Code
43
Insulation Class
H
Inverter Speed Range
Constant 2000:1
Is Motor
Yes
Model Number
449THFS8047
Motor RPM 60 Hertz
1800
Mounting
Rigid
NEMA Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6318
Orientation
Horizontal
Phase
3
RPM
1800
RPM Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
Recognized Construction and Protector
Voltage
460
Weight (lb)
2950
kVA-Code
H
