OEM#: Y525New OEM Original Outright
INVERTER DUTY MOTOR, 143THTN8028, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV by Marathon Motors
Your price:
$1,615.49 each
OEM#: Y525INVERTER DUTY MOTOR, 143THTN8028, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV by Marathon Motors
New OEM Original Outright
Your price:
$1,615.49 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y525, 143THTN8028, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Designed for inverter or vector applications where up to a 2000:1 constant torque speed range is required. Typical use includes: material handling, machine tools, conveyors, crane and hoist, pumps, and other industrial machinery installed in dusty or dirty environments.
Technical Specs
P/N: Y525 Key Specs
Item
INVERTER DUTY MOTOR, 143THTN8028, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV
OEM
Marathon Motors
OEM #
Y525
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
3/1.5
60 Hertz Fl Eff
85.50 Percent
60 Hertz Kw
0.75
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
Ball
Catalog No.
Y525
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Frame
143TC
Horsepower
1
Insulation Class
H
Inverter Speed Range
Constant 2000:1
Ip Code
43
Is_Motor
Yes
Kva-Code
m
Model Number
143THTN8028
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6205
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Thermal Protection
Thermostats (Normally Closed)
Ul
Recognized Construction
Voltage
230/460
Weight In Lbs.
61
Marathon Motors Inverter Duty Motor, Y525, 143THTN8028, 1HP, 230/460V, 1800RPM, 3PH, 143TC, TENV
