OEM#: Y285New OEM Original Outright
INVERTER DUTY MOTOR, 145THTN17034, 2HP, 230/460V, 1800RPM, 3PH, 145TC, TENV by Marathon Motors
Your price:
$2,796.97 each
OEM#: Y285INVERTER DUTY MOTOR, 145THTN17034, 2HP, 230/460V, 1800RPM, 3PH, 145TC, TENV by Marathon Motors
New OEM Original Outright
Your price:
$2,796.97 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y285, 145THTN17034, 2HP, 230/460V, 1800RPM, 3PH, 145TC, TENV
The Max+ incorporates low rotor inertia for fast starts, stops, ad reversals. Coupled with a encoder make this useful in applications traditionally served only by servo systems. The Max+ is also suitable for all applications where up to a 1000:1 Constant Torque speed range.
The Max+ incorporates low rotor inertia for fast starts, stops, ad reversals. Coupled with a encoder make this useful in applications traditionally served only by servo systems. The Max+ is also suitable for all applications where up to a 1000:1 Constant Torque speed range.
Technical Specs
P/N: Y285 Key Specs
Item
INVERTER DUTY MOTOR, 145THTN17034, 2HP, 230/460V, 1800RPM, 3PH, 145TC, TENV
OEM
Marathon Motors
OEM #
Y285
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
6/3
60 Hertz Fl Eff
85.50 Percent
60 Hertz Kw
1.49
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
Ball
Catalog No.
Y285
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Frame
145TC
Horsepower
2
Insulation Class
H
Inverter Speed Range
Constant 1000:1
Ip Code
43
Is_Motor
Yes
Kva-Code
M
Model Number
145THTN17034
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6205
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Ul
Recognized Construction
Voltage
230/460
Weight In Lbs.
75
Marathon Motors Inverter Duty Motor, Y285, 145THTN17034, 2HP, 230/460V, 1800RPM, 3PH, 145TC, TENV
The Max+ incorporates low rotor inertia for fast starts, stops, ad reversals. Coupled with a encoder make this useful in applications traditionally served only by servo systems. The Max+ is also suitable for all applications where up to a 1000:1 Constant Torque speed range.
The Max+ incorporates low rotor inertia for fast starts, stops, ad reversals. Coupled with a encoder make this useful in applications traditionally served only by servo systems. The Max+ is also suitable for all applications where up to a 1000:1 Constant Torque speed range.
