OEM#: X603New OEM Original Outright
COMMERCIAL MOTOR, 56C17D5346, 3/4HP, 115/208-230V, 1725RPM, 1PH, DP by Marathon Motors
Your price:
$773.22 each
OEM#: X603COMMERCIAL MOTOR, 56C17D5346, 3/4HP, 115/208-230V, 1725RPM, 1PH, DP by Marathon Motors
New OEM Original Outright
Your price:
$773.22 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Commercial Motor, X603, 56C17D5346, 3/4HP, 115/208-230V, 1725RPM, 1PH, DP
Commercial laundry dryer motors. Designed to replace Huebsch commercial laundry dryer motors. Equipped with automatic reset thermal protection, a special threaded shaft extension and ball bearings.
Commercial laundry dryer motors. Designed to replace Huebsch commercial laundry dryer motors. Equipped with automatic reset thermal protection, a special threaded shaft extension and ball bearings.
Technical Specs
P/N: X603 Key Specs
Item
COMMERCIAL MOTOR, 56C17D5346, 3/4HP, 115/208-230V, 1725RPM, 1PH, DP
OEM
Marathon Motors
OEM #
X603
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz FL Amps
12/5.8-6
60 Hertz SF
1.25
60 Hertz kW
0.56
Ambient Temperature (°C)
40
Assembly
F1 Only
Bearing Drive End
Ball
CSA
Y
Catalog Number
X603
Country of Origin
USA
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Frame
56C
Horsepower
3/4
IP Code
12
Insulation Class
B
Model Number
56C17D5346
Motor RPM 60 Hertz
1725
Mounting
Resilient Base
NEMA Design
Definite Duty
Opposite End Bearing
Ball
Opposite End Bearing Size
6205
Orientation
Horizontal
Phase
1
RPM
1725
RPM Range
1701-1800
Rotation
CCW
Starting Type
Cap Start Ind Run
Thermal Protection
Automatic Protector
Ul
Recognized Construction and Protector
Voltage
115/208-230
Weight (lb)
29
kVA-Code
K
Marathon Motors Commercial Motor, X603, 56C17D5346, 3/4HP, 115/208-230V, 1725RPM, 1PH, DP
Commercial laundry dryer motors. Designed to replace Huebsch commercial laundry dryer motors. Equipped with automatic reset thermal protection, a special threaded shaft extension and ball bearings.
Commercial laundry dryer motors. Designed to replace Huebsch commercial laundry dryer motors. Equipped with automatic reset thermal protection, a special threaded shaft extension and ball bearings.
