OEM#: X602New OEM Original Outright
COMMERCIAL MOTOR, 56C17D2102, 1/2HP, 115/208-230V, 1725RPM, 1PH, DP by Marathon Motors
Your price:
$620.22 each
OEM#: X602COMMERCIAL MOTOR, 56C17D2102, 1/2HP, 115/208-230V, 1725RPM, 1PH, DP by Marathon Motors
New OEM Original Outright
Your price:
$620.22 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Commercial Motor, X602, 56C17D2102, 1/2HP, 115/208-230V, 1725RPM, 1PH, DP
Commercial laundry dryer motors. Designed to replace Huebsch commercial laundry dryer motors. Equipped with automatic reset thermal protection, a special threaded shaft extension and ball bearings.
Commercial laundry dryer motors. Designed to replace Huebsch commercial laundry dryer motors. Equipped with automatic reset thermal protection, a special threaded shaft extension and ball bearings.
Technical Specs
P/N: X602 Key Specs
Item
COMMERCIAL MOTOR, 56C17D2102, 1/2HP, 115/208-230V, 1725RPM, 1PH, DP
OEM
Marathon Motors
OEM #
X602
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
8/4-4
60 Hertz Kw
0.37
60 Hertz Sf
1.25
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
Ball
Catalog No.
X602
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Frame
56C
Horsepower
1/2
Insulation Class
B
Ip Code
22
Kva-Code
E
Model Number
56C17D2102
Motor Rpm 60Hz
1725
Mounting
Resilient Base
Nema Design
No Design Code
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1725
Rpm Range
1701-1800
Starting Type
Cap Start Ind Run
Thermal Protection
Automatic Protector
Ul
Recognized Construction and Protector
Voltage
115/208-230
Weight In Lbs.
24
