OEM#: X601New OEM Original Outright

COMMERCIAL MOTOR, 56C17D2101, 1/3HP, 115/208-230V, 1725RPM, 1PH, DP by Marathon Motors

Your price:
$519.77 eachReady to ship
HomeMarathon MotorsX601
COMMERCIAL MOTOR, 56C17D2101, 1/3HP, 115/208-230V, 1725RPM, 1PH, DP by Marathon Motors
COMMERCIAL MOTOR, 56C17D2101, 1/3HP, 115/208-230V, 1725RPM, 1PH, DP by Marathon Motors

OEM#: X601
COMMERCIAL MOTOR, 56C17D2101, 1/3HP, 115/208-230V, 1725RPM, 1PH, DP by Marathon Motors

New OEM Original Outright
Your price:
$519.77 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Commercial Motor, X601, 56C17D2101, 1/3HP, 115/208-230V, 1725RPM, 1PH, DP

Commercial laundry dryer motors. Designed to replace Huebsch commercial laundry dryer motors. Equipped with automatic reset thermal protection, a special threaded shaft extension and ball bearings.

Technical Specs
P/N: X601 Key Specs
Item
COMMERCIAL MOTOR, 56C17D2101, 1/3HP, 115/208-230V, 1725RPM, 1PH, DP
OEM
Marathon Motors
OEM #
X601
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
5.8/2.8-2.9
60 Hertz Kw
0.25
60 Hertz Sf
1.35
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
Ball
Catalog No.
X601
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Frame
56C
Horsepower
1/3
Insulation Class
B
Ip Code
22
Kva-Code
K
Model Number
56C17D2101
Motor Rpm 60Hz
1725
Mounting
Resilient Base
Nema Design
No Design Code
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1725
Rpm Range
1701-1800
Starting Type
Cap Start Ind Run
Thermal Protection
Automatic Protector
Ul
Recognized Construction and Protector
Voltage
115/208-230
Weight In Lbs.
20
Marathon Motors Commercial Motor, X601, 56C17D2101, 1/3HP, 115/208-230V, 1725RPM, 1PH, DP

Commercial laundry dryer motors. Designed to replace Huebsch commercial laundry dryer motors. Equipped with automatic reset thermal protection, a special threaded shaft extension and ball bearings.
