OEM#: X028New OEM Original Outright

1/3HP, 115/230V, 1075RPM, 1PH, TEAO, 48YZ FR by Marathon Motors

Your price:
$369.69 eachReady to ship
HomeMarathon MotorsX028
1/3HP, 115/230V, 1075RPM, 1PH, TEAO, 48YZ FR by Marathon Motors
1/3HP, 115/230V, 1075RPM, 1PH, TEAO, 48YZ FR by Marathon Motors

OEM#: X028
1/3HP, 115/230V, 1075RPM, 1PH, TEAO, 48YZ FR by Marathon Motors

New OEM Original Outright
Your price:
$369.69 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors X028, 1/3HP, 115/230V, 1075RPM, 1PH, TEAO, 48YZ FR

These motors are designed for many of the varied applications found on the farm. Designs include motors suitable for aeration fans, auger drives, grain stirring, metering pumps, instant reversing, irrigation tower drives, and crop driers.

Technical Specs
P/N: X028 Key Specs
Item
1/3HP, 115/230V, 1075RPM, 1PH, TEAO, 48YZ FR
OEM
Marathon Motors
OEM #
X028
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Catalog Number
X028
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous AOM
Enclosure
TEAO
Enclosure Type
Totally Enclosed
Fl Amps
4.2/2.1
Frame
48YZ
Horsepower
1/3
Insulation Class
B
Ip Code
43
Is_Motor
Yes
Kilowats
0.25
Kva-Code
B
Model Number
48A11T2022
Motor Rpm 60Hz
1075
Mounting
Resilient Base/Stud
Nema Design
No Design Code
Opposite End Bearing
Ball
Opposite End Bearing Size
Ball
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1075
Rpm Range
1001-1100
Service Factor
1
Starting Type
PSC 1 Speed
Thermal Protection
Automatic Protector (under locked rotor only)
Ul
Recognized Construction and Protector
Voltage
115/230
Weight
21
Marathon Motors X028, 1/3HP, 115/230V, 1075RPM, 1PH, TEAO, 48YZ FR
