OEM#: W642New OEM Original Outright
SEVERE DUTY MOTOR, 445THFN19034, 200HP, 575V, 1800RPM, 3PH, 445T FR, TEFC by Marathon Motors
Your price:
$24,312.12 each
OEM#: W642SEVERE DUTY MOTOR, 445THFN19034, 200HP, 575V, 1800RPM, 3PH, 445T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$24,312.12 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Severe Duty Motor, W642, 445THFN19034, 200HP, 575V, 1800RPM, 3PH, 445T FR, TEFC
Marathon's 1800 Rpm, line of 575 Volts, Severe Duty Neman Premium XRI Duty IEEE-841 Hazardous Duty Motor are available in TEFC construction. Horsepower sizes available from stock range from 1 HP through 200 HP.
Marathon's 1800 Rpm, line of 575 Volts, Severe Duty Neman Premium XRI Duty IEEE-841 Hazardous Duty Motor are available in TEFC construction. Horsepower sizes available from stock range from 1 HP through 200 HP.
Technical Specs
P/N: W642 Key Specs
Item
SEVERE DUTY MOTOR, 445THFN19034, 200HP, 575V, 1800RPM, 3PH, 445T FR, TEFC
OEM
Marathon Motors
OEM #
W642
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
149
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
6318
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6318
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
181
Fl Efficiency
96.2
Frame
445T
Hazardous Location
DIVISION 2 T2B
Horsepower
200
Insulation Class
F
Inverter Speed Range
Constant 2:1
Ip Code
56
Is_Motor
Yes
Kva-Code
G
Model Number
445THFN19034
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
6316
Opposite End Bearing Size
6316
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
575
Weight
2376
