OEM#: U786New OEM Original Outright
PREMIUM EFFICIENCY MOTOR, 250HP, 1800RPM, 460V, 3PH, 447T FR, DP by Marathon Motors
Your price:
$21,009.23 each
OEM#: U786PREMIUM EFFICIENCY MOTOR, 250HP, 1800RPM, 460V, 3PH, 447T FR, DP by Marathon Motors
New OEM Original Outright
Your price:
$21,009.23 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Premium Efficiency Motor, U786, 250HP, 1800RPM, 460V, 3PH, 447T FR, DP
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Technical Specs
P/N: U786 Key Specs
Item
PREMIUM EFFICIENCY MOTOR, 250HP, 1800RPM, 460V, 3PH, 447T FR, DP
OEM
Marathon Motors
OEM #
U786
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
187
Ambient Temp C
40
Approval-Ce
Y
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
6318
Bearing-Opp-Drive-End
6314
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6318
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
284
Fl Efficiency
95.8
Frame
447T
Horsepower
250
Insulation Class
Y
Ip Code
12
Is_Motor
Yes
Kva-Code
F
Model Number
447TTDN16046
Motor Rpm 60Hz
1800
Mounting
Rigid
Nameplate Rpm
1800
Nema Design
B
Opposite End Bearing Size
6314
Orientation
Horizontal
Phase
3
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
PWS YDRUN
Ul
Recognized Construction
Voltage
460
Weight
2133
