OEM#: U003ANew OEM Original Outright
EXPLOSION PROOF EXPLOSION PROOF MOTOR, 145 by Marathon Motors
Your price:
$1,157.30 each
OEM#: U003AEXPLOSION PROOF EXPLOSION PROOF MOTOR, 145 by Marathon Motors
New OEM Original Outright
Your price:
$1,157.30 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, U003A, 145TTGN1027, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: U003A Key Specs
Item
EXPLOSION PROOF EXPLOSION PROOF MOTOR, 145
OEM
Marathon Motors
OEM #
U003A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz FL Amps
6/3
50 Hertz FL Eff
82.50 Percent
50 Hertz HP
1 1/2
50 Hertz SF
1.15
50 Hertz Voltage
190/380
50 Hertz kW
1.12
60 Hertz RPM
1800
60 Hertz kW
1.49
Ambient Temperature (°C)
40
Assembly
F1 Only
Bearing Drive End
6205
CE
N
Country of Origin
USA
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Frame
145T
Full Load Amps
6.2-6/3
Full Load Efficiency
85.5
Hazardous Location
EXP PROOF CL I GR D T2A
Hertz
60/50
Horsepower
2
IP Code
54
Insulation Class
F
Is Motor
Yes
Model Number
145TTGN1027
Motor RPM 50 Hertz
1500
Motor RPM 60 Hertz
1800
Mounting
Rigid
NEMA Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
RPM
1800/1500
RPM Range
1701-1800
Service Factor
1.15
Starting Type
Across the Line
Ul
UL Listed
Voltage
208-230/460
Weight
77
kVA-Code
M
Marathon Motors Explosion Proof Motor, U003A, 145TTGN1027, 2HP, 208-230/460V, 1800RPM, 3PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
