OEM#: T015New OEM Original Outright
WOODWORKING MOTOR, 56C34F5339, 1HP, 115/208-230V, 3600RPM, 1PH, 56 FR, TEFC by Marathon Motors
Your price:
$538.36 each
OEM#: T015WOODWORKING MOTOR, 56C34F5339, 1HP, 115/208-230V, 3600RPM, 1PH, 56 FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$538.36 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Woodworking Motor, T015, 56C34F5339, 1HP, 115/208-230V, 3600RPM, 1PH, 56 FR, TEFC
Replacement motors for table saws, planers, lathes and other equipment found in the woodworking and metalworking trades. These totally enclosed, fan cooled motors are well suited for use in dusty and dirty environments or where wood or metal shavings are present.
Replacement motors for table saws, planers, lathes and other equipment found in the woodworking and metalworking trades. These totally enclosed, fan cooled motors are well suited for use in dusty and dirty environments or where wood or metal shavings are present.
Technical Specs
P/N: T015 Key Specs
Item
WOODWORKING MOTOR, 56C34F5339, 1HP, 115/208-230V, 3600RPM, 1PH, 56 FR, TEFC
OEM
Marathon Motors
OEM #
T015
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
12.4/6.7-6.2
60 Hertz Kw
0.75
60 Hertz Sf
1.15
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
Ball
Catalog No.
T015
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
56
Horsepower
1
Insulation Class
B
Ip Code
43
Kva-Code
K
Model Number
56C34F5339
Motor Rpm 60Hz
3600
Mounting
Rigid
Nema Design
L
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
3600
Rpm Range
3001-3600
Starting Type
Cap Start Ind Run
Thermal Protection
Manual Protector
Ul
Recognized Construction and Protector
Voltage
115/208-230
Weight In Lbs.
30
Marathon Motors Woodworking Motor, T015, 56C34F5339, 1HP, 115/208-230V, 3600RPM, 1PH, 56 FR, TEFC
Replacement motors for table saws, planers, lathes and other equipment found in the woodworking and metalworking trades. These totally enclosed, fan cooled motors are well suited for use in dusty and dirty environments or where wood or metal shavings are present.
Replacement motors for table saws, planers, lathes and other equipment found in the woodworking and metalworking trades. These totally enclosed, fan cooled motors are well suited for use in dusty and dirty environments or where wood or metal shavings are present.
