OEM#: R301New OEM Original Outright

METRIC MOTOR, 63T17FH5326, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC by Marathon Motors

Your price:
$526.54 eachReady to ship
HomeMarathon MotorsR301
METRIC MOTOR, 63T17FH5326, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC by Marathon Motors
METRIC MOTOR, 63T17FH5326, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC by Marathon Motors

OEM#: R301
METRIC MOTOR, 63T17FH5326, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC by Marathon Motors

New OEM Original Outright
Your price:
$526.54 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Metric Motor, R301, 63T17FH5326, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC

Marathon's line of Metric Dimension Motors are designed in IEC Frames from D63 through D200L. The motors are available from stock in 50 Hz or 60 Hz. This means that replacement 60 Hz motors are readily available from Marathon to replace metric motors.

Technical Specs
P/N: R301 Key Specs
Item
METRIC MOTOR, 63T17FH5326, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC
OEM
Marathon Motors
OEM #
R301
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
1.2/0.6
50 Hertz Hp
1/4
50 Hertz Kw
0.18
50 Hertz Rpm
1500
50 Hertz Sf
1
50 Hertz Voltage
200/400
60 Hertz Kw
0.18
Ambient Temp C
40
Approval-Ce
Y
Assembly
F3
Bearing-Drive-End
6202
Bearing-Opp-Drive-End
6202
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6202
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
1.0/0.5
Fl Efficiency
0.68
Frame
63
Horsepower
1/4
Insulation Class
F
Ip Code
55
Is_Motor
Yes
Kva-Code
H
Model Number
63T17FH5326
Motor Rpm 60Hz
1800
Mounting
Rigid
Nameplate Rpm
1800
Nema Design
B
Opposite End Bearing Size
6202
Orientation
Horizontal
Phase
3
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
230/460
Weight
12
Marathon Motors Metric Motor, R301, 63T17FH5326, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC

Marathon's line of Metric Dimension Motors are designed in IEC Frames from D63 through D200L. The motors are available from stock in 50 Hz or 60 Hz. This means that replacement 60 Hz motors are readily available from Marathon to replace metric motors.
